Performance Matrix
High-efficiency nanobubble generation and mixing.
| Size | Flow @ 30 PSI | Flow @ 50 PSI | Flow @ 100 PSI |
|---|---|---|---|
| 1.0" | 9 GPM | 12 GPM | 15 GPM |
| 1.5" | 22 GPM | 29 GPM | 39 GPM |
| 2.0" | 37 GPM | 49 GPM | 66 GPM |
| 3.0" | 83 GPM | 107 GPM | 146 GPM |
| 4.0" | 146 GPM | 188 GPM | 257 GPM |
| 6.0" | 333 GPM | 430 GPM | 586 GPM |
| 8.0" | 581 GPM | 750 GPM | 1020 GPM |
| 10.0" | 914 GPM | 1180 GPM | 1600 GPM |
| 12.0" | 1300 GPM | 1673 GPM | 2279 GPM |
General Specifications
- Temperature:
1°C - 60°C (33.8°F - 140°F)
(Avoid freezing) - Working Pressure:
Max 145 PSI (10 Bar) - Construction Material (Piping):
Based on physicochemical fluid characteristics
(e.g., PVC Sch 40/80 or Stainless Steel 316) - Solids Allowed:
Up to ½ solids (Strainer/Mesh filter recommended) - Gaskets:
Viton
Installation Note: Install after batch delivery pump or in recirculation loop. Operates with a downstream pressure differential of 3-5 PSI (0.2 - 0.35 Bar).
Disclaimer: Specifications are for reference only; actual performance varies with fluid properties, operational parameters, and environmental conditions. For precise details, consult our technical team.
